INFINITY
Infinity Mirror ARGB Fan
SLIN 120mm / SLIN 140mm
Black
SLIN 120mm / SLIN 140mm
White
INFINITY MIRROR FAN
A combination of the original UNI FAN SL and AL with a touch of infinity mirror, the SL-Infinity fans glow clear with multi-layer effects from any visible angle.
CENTERED INFINITY MIRROR ARGB
The circular-shaped infinity mirror at the center of the fan is tuned to have multiple layers spaced 0.5mm apart.
SIDE FRAME ARGB
Following the iconic angular lighting style of SL fans, the SL-Infinity fans have 2 thin LED strips on both sides of the fan blade.
ALUMINUM TRIM SURROUNDED INFINITY MIRROR
Surrounding aluminum trims are located on both sides of the frame. The geometric shape of the infinity mirror follows the front ARGB lighting strip in a top and bottom pattern that creates a 3D indented look.
REAR RIM OF LED AROUND THE ALUMINUM LOGO
Inspired by AL fans, there is a bright ARGB rim of light around the LIAN LI logo at the rear.
UNPRECEDENTED MODULARITY
The 2nd generation of UNI FAN SL revisits the interlocking style that can connect up to 4 fans in a cluster and makes cable management simpler and improves compatibility with radiators fittings.
DAISY CHAIN FAN
A pin-to-pad contact point passes the signal and power through the fan cluster.
Fan Blade & Center Infinity Mirror LED
Angle Fan Frame & Side Infinity Mirror LED
Fan Blade & Center Infinity Mirror + Angle Fan Frame & Side Infinity Mirror LED
Option 2. Select the combining lighting mode
Electric Current
Mixing
DAZZLING AT ALL ANGLE
| PRODUCT NAME | LIAN LI UNI FAN SL-INF 120/140 RGB | |||||
|---|---|---|---|---|---|---|
| MODEL | UF-SLIN120-3B BLACK | UF-SLIN120-1B BLACK | UF-SLIN120-3W WHITE | UF-SLIN120-1W WHITE | UF-SLIN140-1B BLACK | UF-SLIN140-1W WHITE |
| COLOR | Black | White | Black | White | ||
| NUMBER OF FANS | 3 | 1 | 3 | 1 | 1 | 1 |
| CONTROLLER | Yes | No | Yes | No | No | No |
| CONNECTOR TYPE | 4 × 7-PIN | 1 × 4-PIN PWM + 3-PIN ARGB | 4 × 7-PIN | 1 × 4-PIN PWM + 3-PIN ARGB | 1 × 4-PIN PWM + 3-PIN ARGB | 1 × 4-PIN PWM + 3-PIN ARGB |
| FAN DIMENSION | 120 X 122.1 X 25 (mm) | 140 X 142 X 25 (mm) | ||||
| RATED VOLTAGE | DC 12V (FAN) & 5V (LED) | |||||
| FAN SPEED | 0,200~2100 RPM | 0,200~1600 RPM | ||||
| MAX. AIR PRESSURE | 2.66 mmH2O (Maximum) | 2.88 mmH2O (Maximum) | ||||
| MAX. AIRFLOW | 61.3 CFM (Maximum) | 72.7 CFM (Maximum) | ||||
| ACOUSTIC NOISE | 29 dB(A) Max | 28 dB(A) Max | ||||
| LOCKED CURRENT | ≧50mA | ≧40mA | ||||
| BEARING TYPE | Fluid Dynamic Bearing (FDB) | |||||
| START-UP VOLTAGE | DC ≦6V | |||||
| INPUT CURRENT | 180mA (FAN) /600mA (LED) | 150mA (FAN) / 600mA(LED) | ||||
| INPUT POWER | 5.16W | 4.56w | ||||
